零件代码 – PART NUMBER

长度length mm	油 – Oil	石化油 – Petrol
L = 53	SOG 053 – 100	无对应信息
L = 65	SOG 065 – 100	SRG 065 – 100
L = 68	SOG 068 – 100	SRG 068 – 100
L = 75	SOG 075 – 100	SRG 075 – 100
L = 85	SOG 085 – 100	SRG 085 – 100
L = 94	SOG 094 – 100	SRG 094 – 100
L = 98	SOG 098 – 100	SRG 098 – 100

零件代码 – PART NUMBER

长度length mm	油 – Oil	石化油 – Petrol
L = 105	SOG 105 – 100	SRG 105 – 100
L = 109	SOG 109 – 100	SRG 109 – 100
L = 125	SOG 125 – 100	SRG 125 – 100
L = 140	SOG 140 – 100	SRG 140 – 100
L = 144	SOG 144 – 100	SRG 144 – 100
L = 192	SOG 192 – 100	SRG 192 – 100

中文参数	中文值	英文参数	英文值
使用范围	矿物油 – 柴油 – 汽油	Use	Mineral oils – Fuels – Diesel fuel
固定	SOG防油丁腈橡胶插口；SRG防石油丁腈橡胶插口	Fixing	SOG anti-oil NBR plug; SRG anti-petrol NBR plug
杆	尼龙	Stem	Nylon
浮球	尼龙泡沫	Float	Foamed nylon
固定触点	镀银黄铜	Fixed contact	Silver plated brass
移动触点	镀银磷青铜	Moving contact	Silver plat. phosphorous bronze
触点类型	机电开关	Type of contact	N.C. electromechanical
开关最大容量	5 W	Max switch. capacity	5 W
开关最大电流	500 mA	Max switch. current	500 mA
开关最大电压	24 Vdc	Max switch. voltage	24 Vdc
液体比重	> 0.85 (SOG) > 0.7 (SRG)	Specific liquid weight	> 0.85 (SOG) > 0.7 (SRG)
工作温度	-10°C / +80°C	Working temperature	-10 / +80°C
重量	~ 30 gr (L=109 mm)	Weight	~ 30 gr (L= 109 mm)
