EUROSWITCH销售中心
主要用途：
—气动
—液压
—压缩机
—农业机械
—建筑机械和车辆
—加工工业
通用技术特点：
—传感元件：陶瓷
—压力范围：—1÷9 …… 0÷600 [bar]
—输出信号：4-20 [mA]
—精度≤1%（满量程）(BSFL – IEC 61298 – 2)
（非线性 + 迟滞 + 重复性）
—电气连接：M12x1
—防护等级：IP 67
—G 1/4”工艺连接按照 DIN 3852-E
按要求定制版本
Main Applications:
– Pneumatic
– Hydraulic
– Air compressors
– Agricultural machinery
– Construction machinery and vehicles
– Process industry
General technical features:
– Sensor element : ceramic
– Measuring range : -1÷9 ……. 0÷600 [bar]
– Output signal : 4-20 [mA] 2-wires
– Accuracy ≤1% (Span) (BSFL – IEC 61298 – 2)
(Non linearity + Hysteresis + Repeatibility)
– Electrical process connection : M12x1
– Protection degree : IP 67
– Thread G 1/4” according to DIN 3852-E (others on request)
Custom versions on request
